Spindle Ø

Diámetro exterior Ø

Spindelhülse-Ø

120mm

Maximum Speed

Velocidad(máximo)

lubricación aire/aceite

Drehzahl(max.)

Öl-Luft-Schmierung

36,000RPM

Tool Interface

Interfaz de herramienta

Werkzeugaufnahme

D22/38

Voltage

Voltaje

Umrichternennspannung

THG-120.02

THG-120.15

Frequency max.

Frequenza(máximo)

Frequenz max.

1,200Hz

at speed

Velocidad Nominal

bei Drehzahl

9,700RPM

kW (S1)

Potencia kW (S1)

Leistung kW (S1)

4.6kW (S1)

Torque Nm(S1)

Par Nm(S1)

Drehmoment Nm(S1)

4.5Nm (S1)

kW (S6-40%)

Potencia kW (S6-40%)

Leistung kW (S6-40%)

6kW (S6-40%)

Torque Nm(S6-40%)

Par Nm(S6-40%)

Drehmoment Nm

(S6-40%)

5.9Nm (S6-40%)

         Download

Descargar

Herunterladen

Application

Aplicación

Anwendung

Spindle Ø

80mm

80mm

100mm

100mm

120mm

Maximum Speed

Grease

Max. 60,000rpm

Max. 60,000rpm

Max. 30,000rpm

Max. 30,000rpm

Max. 30,000rpm

Oil-Air

Max. 105,000rpm

Max. 120,000rpm

Max. 50,000rpm

Max. 75,000rpm

Max. 30,000rpm

kW (S1)

1kW

0.64kW

6.4kW

1.5kW

4.6kW

kW (S6-40%)

1.3kW

0.75kW

8.3kW

1.95kW

6kW

kW (Peak Power)

2.65kW

1.5kW

15kW

4.1kW

14kW

Torque Nm(S1)

0.08Nm

0.04Nm

1.7Nm

0.16Nm

4.5Nm

Torque Nm(S6-40%)

0.1Nm

0.05Nm

2.2Nm

0.21Nm

5.9Nm

Tool Interface

D6/12

Collet

D14/23

D8/14

D22/38

Spindle Cooling

Oil cooling / Water cooling

Spindle Length

186.2mm

175mm

317.5mm

210.5mm

388.5mm

Spindle Weight

4.5kg

4.1kg

15kg

12kg

25kg

Closed-Loop

N/A

N/A

N/A

N/A

Option

Coolant Through Spindle(CTS)

N/A

N/A

Option

Option

Option

Grease Lubricated

Option

Option

Option

Option

Option

Housing flange

N/A

N/A

N/A

N/A

Option

Spindle Ø

120mm

120mm

120mm

120mm

120mm

Maximum Speed

Grease

Max. 30,000rpm

Max. 30,000rpm

Max. 30,000rpm

Max. 30,000rpm

Max. 30,000rpm

Oil-Air

Max. 30,000rpm

Max. 30,000rpm

Max. 30,000rpm

Max. 45,000rpm

Max. 36,000rpm

kW (S1)

10kW

13kW

10kW

10kW

13kW

kW (S6-40%)

13kW

16.9kW

13kW

12.5kW

16.9kW

kW (Peak Power)

25kW

30.6kW

25kW

25kW

30.6kW

Torque Nm(S1)

5.4Nm

3.5Nm

5.4Nm

3.2Nm

3.5Nm

Torque Nm(S6-40%)

7.1Nm

4.5Nm

7.1Nm

4.0Nm

4.5Nm

Tool Interface

D22/38

D22/38

D28/43

D16/28

D28/43

Spindle Cooling

Oil cooling / Water cooling

Spindle Length

388.5mm

388.5mm

388.5mm

346mm

388.5mm

Spindle Weight

25kg

25kg

25kg

25kg

25kg

Closed-Loop

Option

Option

Option

Option

Option

Coolant Through Spindle(CTS)

Option

Option

Option

Option

Option

Grease Lubricated

Option

Option

Option

Option

Option

Housing flange

Option

Option

Option

Option

Option
